Ultra Low-Power, Low-Cost Comparators with 2% Reference MAX931-MAX934 ELECTRICAL CHARACTERISTICS—5V Operation (continued)
(V+ = 5V, V- = GND = 0V, TA = TMIN to TMAX, unless otherwise noted.)
PARAMETER CONDITIONS MIN TYP MAX UNITS
Output High Voltage C/E temp. ranges, IOUT = 17mA V+ – 0.4 V MAX932, V- + 0.4 C/E temp. ranges, MAX933 Output Low Voltage V IOUT = 1.8mA MAX931, GND + 0.4 MAX934 X
REFERENCE
C temp. range 1.158 1.182 1.206 Reference Voltage V E temp. range 1.147 1.217 TA = +25°C 15 25 Source Current µA C/E temp. ranges 6 TA = +25°C 8 15 Sink Current µA C/E temp. ranges 4 Voltage Noise 100Hz to 100kHz 100 µVRMS
Note 1:
MAX934 comparators work below 2.5V, see Low-Voltage Operation section for more details.
ELECTRICAL CHARACTERISTICS—3V Operation
(V+ = 3V, V- = GND = 0V, TA = TMIN to TMAX, unless otherwise noted.)
PARAMETER CONDITIONS MIN TYP MAX UNITS POWER REQUIREMENTS
TA = +25°C 2.4 3.0 MAX931, HYST = REF C/E temp. ranges 3.8 T 3.4 4.3 MAX932, A = +25°C HYST = REF C/E temp. ranges 5.8 Supply Current IN+ = (IN- + 100mV) µA T 3.4 4.3 MAX933, A = +25°C HYST = REF C/E temp. ranges 5.8 TA = +25°C 5.2 6.2 MAX934 C/E temp. ranges 8.0
COMPARATOR
Input Offset Voltage VCM = 1.5V ±10 mV Input Leakage Current (IN-, IN+) IN+ = IN- = 1.5V, C/E temp. ranges ±0.01 ±1 nA Input Leakage Current (HYST) MAX931, MAX932, MAX933 ±0.02 nA
