BridgeSwitch. BridgeSwitch Functional Description. BYPASS LOW-SIDE Pin and HIGH-SIDE Pin. Undervoltage Threshold

BridgeSwitch BridgeSwitch Functional Description BYPASS LOW-SIDE Pin and HIGH-SIDE Pin Undervoltage Threshold

该数据表的模型线

文件文字版本

BridgeSwitch BridgeSwitch Functional Description
R and R in Figure 6). External supply voltage V is greater than SL SH SUP bypass shunt regulator voltage V plus the voltage drop of BridgeSwitch combines two high-voltage power FREDFETs, gate BPX(SHUNT) bootstrap diode D . A typical value is V = 17 V. Resistors R and drivers and control ers into a single package. The FREDFETs are SH SUP SL R limit the external supply current to less than 12 mA (2-5 mA connected in a half-bridge configuration where their diode structure SH recommended). Shorting BPL pins or BPH pins from separate devices (ultra-soft and ultra-fast recovery) makes them ideal for hard- directly together is not recommended. switched inverter-based motor drivers.
BYPASS LOW-SIDE Pin and HIGH-SIDE Pin
To reduce external components, the drive control ers feature integrated
Undervoltage Threshold
high-voltage current sources, al owing them to draw current directly The BYPASS LOW-SIDE pin and BYPASS HIGH-SIDE pin undervoltage from the high-voltage DC Bus. The high-side control er provides circuitries disable the respective power FREDFET when either the high-side status updates to the low-side control er which generates BYPASS LOW-SIDE pin voltage or the BYPASS HIGH-SIDE pin voltage an instantaneous phase-current output signal (BRD126X). This drops below V -V or V -V , respectively, in steady-state BPL BPL(HYST) BPH BPH(HYST) unique capability al ows the implementation of a sensor-less operation. Once either the BYPASS LOW-SIDE pin voltage or the motor-control scheme. The control ers also ensure that the FREDFET BYPASS HIGH-SIDE pin voltage fal below this threshold, it must rise turn-off is faster than turn-on resulting in an optimal balance back up to V or V , respectively to enable power FREDFET switching. BPL BPH between thermal performance and EMI.
BYPASS LOW-SIDE Pin and HIGH-SIDE Pins
BridgeSwitch offers integrated fault protection and system level
Capacitor Selection
monitoring via a bi-directional bussed single-wire status interface. Capacitors connected to the BYPASS LOW-SIDE pin and BYPASS Internal fault protection includes cycle-by-cycle current limit for both HIGH-SIDE pin supply bias current for the low-side and the high-side FREDFETs as well as two-level thermal overload protection. control er and deliver the required Gate charge for turning on the BridgeSwitch offers sophisticated DC-bus sensing, providing four low-side or the high-side power FREDFET. The BYPASS HIGH-SIDE pin undervoltage levels and one overvoltage level, and can also support capacitor supplies the high-side control er bias current over a time external sensors such as an NTC. Figure 3 shows the functional block interval which is a function of the high-side commutation duty ratio and diagram of the device along with key features. PWM frequency. The recommended maximum voltage ripple at the
BYPASS LOW-SIDE Pin and HIGH-SIDE Pin Regulator
BYPASS HIGH-SIDE pin capacitor over this time interval is 250 mV. The minimum required capacitance value for both bypass low-side and The BYPASS LOW-SIDE pin and the BYPASS HIGH-SIDE pin have bypass high-side is 0.33 internal regulators that charge the BYPASS LOW-SIDE pin capacitor mF. The recommended bypass low-side capacitance is 1 and the BYPASS HIGH-SIDE pin capacitor to V and V , respec- mF. BPL BPH tively. A current source connected to HIGH-SIDE DRAIN charges the Given application operating conditions determine the required bypass BYPASS LOW-SIDE capacitor. Another current source connected to high-side capacitance to keep ripple voltage below 250 mV. Figure 7 HIGH-SIDE DRAIN charges the BYPASS HIGH-SIDE capacitor depicts the minimum recommended BYPASS HIGH-SIDE pin capaci- whenever the low-side power FREDFET turns on. Both current sources tance as function of high-side commutation duty ratio D and PWM HS start charging once the HD pin voltage reaches V (min. 50 V). frequency. HD(START) The BYPASS LOW-SIDE and the BYPASS HIGH-SIDE pins are the internal supply voltage nodes for the low-side and the high-side 100 control ers and Gate drivers. When the low-side or the high-side f(PWM) 100 power FREDFETs are on, the device operates from the energy stored 500 in the BYPASS LOW-SIDE pin capacitor or the BYPASS HIGH-SIDE pin 1000 6000 capacitor, respectively.
PI-8309-080918
10000 10 16000 In addition, there are shunt regulators clamping the BYPASS LOW-SIDE 20000 pin to V and the BYPASS HIGH-SIDE pin to V when BPL(SHUNT) BPH(SHUNT) current is provided to the BYPASS LOW-SIDE pin and the BYPASS HIGH-SIDE pin from an external DC source through resistors (see 1
apacitance (
µ
F) Minimum recommended value in C HV Bus P H P HD B
0.1
BPH
CBPH RSH
HB
DSH
BPL
0.010.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 RSL CBPL
SG LS Maximum High-Side Commutation Duty Ratio DHS(MAX)
VSUP
+ -
Figure 7. BYPASS HIGH-SIDE Pin Capacitance vs. High-Side Commutation Duty Ratio and PWM Frequency. PI-8313-110518 Note that multilayer chip capacitors (MLCC) can exhibit a significant DC bias characteristic. Selecting a BYPASS HIGH-SIDE pin capacitor Figure 6. External BPL Pin and BPH Pin Power Supply Example. (according to Figure 7) needs to take the possible capacitance reduction into account when biasing at V . Refer to the respective BPH capacitor data sheet for details.
5
