REVISIONS LTR DESCRIPTION DATE (YR-MO-DA) APPROVED A Add case outline 2. Add input voltage test. Add footnote 3/. Editorial changes 90-03-30 M. POELKING throughout. B Change boilerplate to add one-part part numbers. 97-12-08 R. MONNIN Add table IIB for delta limits. - rrp C Add radiation hardened assurance requirements. - lgt 99-03-01 R. MONNIN D Replaced reference to MIL-STD-973 with reference to MIL-PRF-38535. 04-08-06 R. MONNIN Drawing updated to reflect current requirements. - gt E Add a new footnote under paragraph 1.5 and Table I. - ro 05-08-09 R. MONNIN F Update drawing to reflect current requirements. Changes to 1.5. Deleted 11-02-16 C. SAFFLE unused group E boilerplate paragraphs. -rrp Removed figure 3, radiation exposure circuit. Update drawing to current G 17-07-25 C. SAFFLE MIL-PRF-38535 requirements. -rrp

THE ORIGINAL FIRST SHEET OF THIS DRAWING HAS BEEN REPLACED. REV SHEET REV SHEET REV STATUS REV G G G G G G G G G G G G G OF SHEETS SHEET 1 2 3 4 5 6 7 8 9 10 11 12 13 PMIC N/A PREPARED BY JOSEPH A. KERBY
DLA LAND AND MARITIME COLUMBUS, OHIO 43218-3990 STANDARD
CHECKED BY
http://www.landandmaritime.dla.mil MICROCIRCUIT
D. A. DiCENZO
DRAWING
APPROVED BY MICHAEL A. FRYE THIS DRAWING IS AVAILABLE MICROCIRCUIT, LINEAR, RADIATION FOR USE BY ALL HARDENED, PRECISION INSTRUMENTATION DEPARTMENTS DRAWING APPROVAL DATE AND AGENCIES OF THE 88-02-10 AMPLIFIER, MONOLITHIC SILICON DEPARTMENT OF DEFENSE REVISION LEVEL SIZE CAGE CODE AMSC N/A
5962-88539
G A
67268
SHEET 1 OF 13 DSCC FORM 2233 APR 97 5962-E465-17 DISTRIBUTION STATEMENT A. Approved for public release. Distribution is unlimited.
