Actuation type | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool | Operating tool |
Clamping spring material | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) | Chrome nickel spring steel (CrNi) |
Color | gray | gray | black | gray | black | gray | black | gray | black | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | black | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | black | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray | gray |
Conductor entry angle to the PCB, ° | | | 90 | | 90 | | 90 | | 90 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
Connection technology | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® | Push-in CAGE CLAMP® |
Contact material | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) | Electrolytic copper (Ecu) |
Contact plating | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated | tin-plated |
Страна происхождения | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE | DE |
Depth | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch |
Drilled hole diameter (tolerance), mm | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) | 1.3(+ 0.1) |
Fine-stranded conductor | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG |
Fine-stranded conductor with ferrule with plastic collar | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² |
Fine-stranded conductor with ferrule without plastic collar | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² | 0.25 … 2.5 mm² |
Fine-stranded conductor, with twin ferrule | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² | 0.25 … 1.5 mm² |
Fire load, MJ | 0.008 | 0.008 | | 0.008 | | 0.008 | | 0.008 | | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 | 0.038 | 0.068 | 0.098 | | 0.158 | 0.188 | 0.218 | 0.248 | 0.278 | 0.308 | 0.338 | 0.038 | 0.068 | 0.098 | | 0.128 | 0.158 | 0.188 | 0.218 | 0.248 | 0.278 | 0.308 | 0.338 | 0.028 | | | | | | | | | | | 0.228 | | 0.28 | | | | 0.148 | | 0.208 | 0.238 | 0.268 | 0.298 | 0.328 | 0.358 | | | | | | 0.208 | | 0.268 | 0.298 | 0.328 | 0.358 |
Flammability class per UL94 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 | V0 |
Global Trade Item Number (GTIN) | 4055143578295 | 4055143578301 | 4055143762144 | 4055143578318 | 4055143762151 | 4055143578325 | 4055143762175 | 4055143578332 | 4055143762182 | 4055143578349 | 4055143578356 | 4055143578363 | 4055143578370 | 4055143578387 | 4055143578394 | 4055143578400 | 4055143578417 | 4055143578424 | 4055143578431 | 4055143578448 | 4055143578479 | 4055143578486 | 4055143578493 | 4055143578509 | 4055143578516 | 4055143578523 | 4055143578530 | 4055143578547 | 4055143578554 | 4055143578578 | 4055143764056 | 4055143578585 | 4055143578608 | 4055143578622 | 4055143578646 | 4055143578653 | 4055143578677 | 4055143578691 | 4055143578707 | 4055143578721 | 4055143578738 | 4055143758642 | 4055143578752 | 4055143578769 | 4055143578776 | 4055143578783 | 4055143578790 | 4055143578806 | 4055143578813 | 4055143578820 | 4055143578837 | 4055143578844 | 4055143657341 | 4055143579537 | 4055143582506 | 4055143582520 | 4055143582537 | 4055143582551 | 4055143582568 | 4055143582575 | 4055143582582 | 4055143582599 | 4055143582605 | 4055143582612 | 4055143579582 | 4055143579599 | 4055143579605 | 4055143579612 | 4055143579636 | 4055143579674 | 4055143579681 | 4055143579759 | 4055143579773 | 4055143579780 | 4055143579797 |
Height | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 19.4 mm / 0.764 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch | 20.3 mm / 0.799 inch |
Height from the surface | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 15.4 mm / 0.606 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch | 16.3 mm / 0.642 inch |
Insulating material | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) | Polyamide 66 (PA 66) |
Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
Limit temperature range | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C | -60 … +105 °C |
Material group | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I |
Number of Poles | 1 | 2 | 2 | 3 | 3 | 4 | 4 | 5 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 1 | 2 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 14 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Number of connection types | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Number of levels | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Number of solder pins per potential | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
PCB contact | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT | THT |
Packaging type | | | BOX | | BOX | | BOX | | BOX | | | | | | | | | | | | | | | | | | | | | | BOX | | | | | | | | | | | BOX | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
Pin spacing | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 5 mm (0.197 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 7.5 mm (0.295 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) | 11.5 mm (0.453 inch) |
Rated current, A | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 | 41 |
Rated impulse voltage (II / 2), kV | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
Rated impulse voltage (III / 2), kV | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
Rated impulse voltage (III / 3), kV | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
Rated voltage (II / 2), V | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
Rated voltage (III / 2), V | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
Rated voltage (III / 3), V | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 630 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
Solder pin arrangement | within the terminal block, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | within the terminal block, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line | over the entire terminal strip, in line |
Solder pin dimensions | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm | 0.8 x 1 mm |
Solder pin length, mm | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
Solid conductor | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG | 0.2 … 6 mm² / 24 … 10 AWG |
Strip length | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch | 10 … 12 mm / 0.39 … 0.47 Inch |
Total number of connection points | 1 | 2 | 2 | 3 | 3 | 4 | 4 | 5 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 1 | 2 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 14 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Total number of potentials | 1 | 2 | 2 | 3 | 3 | 4 | 4 | 5 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 1 | 2 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 14 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Type of mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting | Feed-through mounting |
Weight, g | 1.89 | 3.39 | 3.39 | 4.85 | 4.94 | 6.36 | 6.49 | 7.93 | 8.04 | 9.65 | 11.49 | 12.85 | 14.69 | 15.22 | 17.89 | 19.49 | 3.74 | 5.6 | 7.4 | 9.29 | 11.14 | 12.99 | 14.84 | 16.69 | 18.54 | 20.39 | 22.24 | 4.32 | 6.75 | 9.3 | 9.13 | 11.61 | 14.04 | 16.47 | 19.05 | 21.33 | 23.76 | 26.19 | 28.62 | 1.864 | 3.438 | 3.438 | 5.012 | 6.586 | 8.16 | 9.734 | 11.308 | 12.882 | 14.456 | 16.03 | 17.604 | 19.178 | 22.326 | 3.748 | 5.632 | 7.516 | 9.4 | 11.284 | 13.168 | 15.052 | 16.936 | 18.82 | 20.704 | 22.588 | 4.328 | 6.792 | 9.256 | 11.72 | 14.184 | 16.648 | 19.112 | 21.576 | 24.04 | 26.504 | 28.968 |
Width | 6.5 mm / 0.256 inch | 11.5 mm / 0.453 inch | 11.5 mm / 0.453 inch | 16.5 mm / 0.65 inch | 16.5 mm / 0.65 inch | 21.5 mm / 0.846 inch | 21.5 mm / 0.846 inch | 26.5 mm / 1.043 inch | 26.5 mm / 1.043 inch | 31.5 mm / 1.24 inch | 36.5 mm / 1.437 inch | 41.5 mm / 1.634 inch | 46.5 mm / 1.831 inch | 51.5 mm / 2.028 inch | 56.5 mm / 2.224 inch | 61.5 mm / 2.421 inch | 14 mm / 0.551 inch | 21.5 mm / 0.846 inch | 29 mm / 1.142 inch | 36.5 mm / 1.437 inch | 44 mm / 1.732 inch | 51.5 mm / 2.028 inch | 59 mm / 2.323 inch | 66.5 mm / 2.618 inch | 74 mm / 2.913 inch | 81.5 mm / 3.209 inch | 89 mm / 3.504 inch | 18 mm / 0.709 inch | 29.5 mm / 1.161 inch | 41 mm / 1.614 inch | 41 mm / 1.614 inch | 52.5 mm / 2.067 inch | 64 mm / 2.52 inch | 75.5 mm / 2.972 inch | 87 mm / 3.425 inch | 98.5 mm / 3.878 inch | 110 mm / 4.331 inch | 121.5 mm / 4.783 inch | 133 mm / 5.236 inch | 6.5 mm / 0.256 inch | 11.5 mm / 0.453 inch | 11.5 mm / 0.453 inch | 16.5 mm / 0.65 inch | 21.5 mm / 0.846 inch | 26.5 mm / 1.043 inch | 31.5 mm / 1.24 inch | 36.5 mm / 1.437 inch | 41.5 mm / 1.634 inch | 46.5 mm / 1.831 inch | 51.5 mm / 2.028 inch | 56.5 mm / 2.224 inch | 61.5 mm / 2.421 inch | 71.5 mm / 2.815 inch | 14 mm / 0.551 inch | 21.5 mm / 0.846 inch | 29 mm / 1.142 inch | 36.5 mm / 1.437 inch | 44 mm / 1.732 inch | 51.5 mm / 2.028 inch | 59 mm / 2.323 inch | 66.5 mm / 2.618 inch | 74 mm / 2.913 inch | 81.5 mm / 3.209 inch | 89 mm / 3.504 inch | 18 mm / 0.709 inch | 29.5 mm / 1.161 inch | 41 mm / 1.614 inch | 52.5 mm / 2.067 inch | 64 mm / 2.52 inch | 75.5 mm / 2.972 inch | 87 mm / 3.425 inch | 98.5 mm / 3.878 inch | 110 mm / 4.331 inch | 121.5 mm / 4.783 inch | 133 mm / 5.236 inch |
