Datasheet Wago 400-425/425-216 — 数据表

螺钉式直通型接线端子； 70毫米²;用于DIN导轨35 x 15和35 x 7.5

参数化

Actuation type	Operating tool
Color	blue
Connectable conductor materials	Copper
Connection technology	Screw-clamp connection/Studs
Страна происхождения	FR
Depth	74 mm / 2.913 inch
Design	horizontal
Global Trade Item Number (GTIN)	4017332280426
Height from upper-edge of DIN-35 rail	67.5 mm / 2.657 inch
Legend (ratings)	(III / 3) ≙ Overvoltage category III / Pollution degree 3
Marking level	Side marking
Number of levels	1
Product Group	1 (Rail Mounted Terminal Blocks)
Rated current	192 A
Rated impulse voltage (III / 3)	8 kV
Rated voltage (III / 3)	1000 V
Solid conductor	16 … 70 mm² / 6 … 2/0 AWG
Strip length	25 … 27 mm / 0.98 … 1.06 Inch
Total number of connection points	2
Total number of potentials	1
Type of mounting	DIN-35 rail
Type of wiring	Side-entry wiring
Weight	160.9 g
Width	22 mm / 0.866 inch

系列: 400 (62)

400425/425216, 400 425/425 216
